Nuts
ONKAR INTERNATIONAL manufactures a comprehensive range of nuts using both hot forging, cold forming, bar turning and milling processes. Our regular production includes the following specifications
ISO, DIN, BS, AS, ANSI, NEN, JIS
We also manufacture special application/profile nuts to customer's requirements and specifications.Our standard size range of nuts are available from Diameters M 6 TO M 100 and also in corresponding Inch sizes Diameters 1/4" TO 4".
|
Type
|
Range
(Metric) |
Grade
|
Range
(Inch) |
Class
|
|
Hex/Square Nuts
|
M6-M100
|
4,5,6,8,10
|
1/4"-4"
|
2,5,8
|
|
Round/Rect. Nuts
|
M6-M100
|
4,5,6,8,10
|
1/4"-4"
|
2,5,8
|
|
Nylon insert Nuts
|
M8-M64
|
6,8,10
|
3/8"-2.1/2"
|
2,5,8
|
|
Heavy Hex Nuts
|
M12-M100
|
8,10
|
1/2"-4"
|
5,8
|
|
H.S.F.G. Nuts
|
M12-M48
|
8,10
|
1/2"-2"
|
5,8
|
|
Castle/slotted Nuts
|
M8-M100
|
5,8,10
|
3/8"-4"
|
2,5,8
|
|
Flanged Nuts
|
M16-M64
|
6,8,10
|
5/8"-2.1/2"
|
2,5,8
|
|
Jam Nuts
|
M12-M64
|
6,8,10
|
1/2"-2.1/2"
|
2,5,8
|
|
2H Nuts
|
M12-M64
|
6,8,10
|
1/2"-2.1/2"
|
2,5,8
|
|
Coupling Nuts
|
M6-M64
|
5,6,8,10
|
1/4"-2.1/2"
|
2,5,8
|
|
T Nuts
|
M12-M30
|
8,10
|
1/2"-1.1/4"
|
2,5,8
|
|
Spring Nuts
|
M6-M24
|
6,8,10
|
1/4"-1"
|
2,5,8
|
|
Nut Blanks
|
M12-M100
|
6,8,10
|
1/2"-4"
|
2,5,8
|
Materials
Mild steelHigh Carbon Steel
Alloy Steel
Brass
Stainless Steel
The Finish
Self-color Black Phosphated zinc plated (white, yellow & black)CR3 zinc Hot Dip galvanized Chrome plated Powder coated finishes.
CR3 zinc Hot Dip galvanized Chrome plated Powder coated finishes.
Thread Types
We can produce all types of nuts to Metric, Witworth, Unified and Trapezoidal threads in Standard and Fine pitches, and unconventional thread pitches for specialised applications.We also have the expertise to Hot Dip Galvanise / Powder Coat Nylon Insert Nuts
Our Thrust:
We manufacture big nuts upto M100 or 4" using forging or bar turning operations. Our large diameter nuts have world-wide acceptability in fields such as heavy machine assemblies, construction and mining. We also manufacture the extra long and the very thin nuts' with customised and unconventional thread pitches for specialized applications.
